Rated voltage： 300/300V
Conductor: BS 6360 Class 5, stranded, annealed copper wire
Insulation: BS 7655 T1 1 PVC Compound
Insulation Color: Red, yellow, blue, black, green, white, purple, gray, orange, pink
Operating temperature: 0 to 70℃
Usable under very low mechanical stress in households and office rooms for light handheld devices
BS 6500
Rated voltage： 300/300V
Conductor: BS 6360 Class 5, stranded, annealed copper wire
Insulation: BS 7655 T1 1 PVC Compound
Insulation Color: Red, yellow, blue, black, green, white, purple, gray, orange, pink
Operating temperature: 0 to 70℃
Min bending radius: 6 x overall insulted diameter
| Nominal Cross Section (mm2) | Conductor (Nos/mm) | Insulation Thickness (mm) | Max Overall Diameter (mm) | Mass of wire (kg/km) | Structure of cable |
| 0.5 | 2 x 28/0.15 | 0.8 | 3 x 5.9 | 24.0 | 1 |
| 0.75 | 2 x 42/0.15 | 0.8 | 3 x 6.3 | 30.5 | 1 |
