8.7/10kV (15kV) Copper Conductor XLPE Insulated Underground Medium Voltage Power Cable

  • 8.7/10kV YJV / YJLV / YJV22 / YJLV22 / YJV32 / YJLV32
  • RMJT
  • IEC 60502-3
Quantity:

Introduction

This cable is used to transmit power on the power transmission and distribution line of A.C.50Hz, rated voltage 35kV or lower. In comparison with PVC insulation cable, it boasts not only excellent electric character, mechanical character, heat and aging-resistant character, environmental stress-resistant character and chemical corrosion- resistant character, but simple structure, light weight, no restriction by laying drop, and high temperature allowance for long-term working as well.


Working conditions:

1This maximum working temperature of the conductor is 90 0C;

During having a short (lasting less than 5 seconds) the maximum temperature of the cable conductor shall       not be above 250 0C; Environment temperature should be no lower than 00C for laying the cable;

2Bending radius allowance of the cable:

 Single core cable: No steel tape cable 20D; Steel tape cable 15D

Cores cable:  No steel tape cable 15D; Steel tape cable 12D.

 Notes: D practical external diameter of cable.


Type Description & Application Occasion of cable

Type

Description

Application Occasion

Cu

Al

YJV

YJLV

XLPE insulation   PVC sheath power cable

To be laid   indoors, in tunnel, cable furrow or pipe, the cable couldn't bear mechanical force outside

YJY

YJLY

XLPE insulation   PE sheath power cable

YJV22

YJLV22

 XLPE insulation, steel tape armor,    PVC sheath power cable

To be laid   underground, the cable could bear certain mechanical force, but it couldn't bear great pulling force.

YJV23

YJLV23

XLPE insulation, steel tape armor,    PE sheath power cable

YJV62

YJLV62

XLPE insulation,   have no the magnetism steel tape   armor,  PE sheath power cable

YJV32

YJLV32

XLPE insulation,   thin steel-wire  armor,  PVC sheath power cable

Be applicable to   the well, water inside and fall in the bad soil, the cable cans bear the   equal dint outside the machine with pull the dint



.

YJV72

YJLV72

XLPE insulation,   have no the magnetism thick steel-wire    armor,  PVC sheath power cable

YJV42

YJLV42

XLPE insulation,   thick steel-wire  armor,  PVC sheath power cable

Be applicable to   the well, underwater with the bottom of sea, the cable cans bear the bigger   pressure with lead to pull the dint.

Hint Specially

The single-core magnetism material packs   the cable is not suitable for to use for the AC power supply back track, the   necessity hour eligibility uses the single-core 62 or 72 type pack the cable.

Disallow the cent to cross the magnetism   piping mutually when single-core cable establish, the in order to prevent   results in the descent that cable transport electric current ability.


Test Voltage and biggest Discharge capacity of cable

Rated Voltage

         (kV)

3.6/6

6/6

6/10

8.7/10

8.7/15

12/20

18/30

21/35

26/35

Test Voltage

     (kV

6.23

10.38

15.05

20.76

31.14

36.33

44.98

Discharge capacity

     (pC

10

10

10

10

10

10

10



AC voltage test of cable

Rated Voltage

        kV

0.6/1

1.8/3

3.6/6

3.6/10

6/6

6/10

8.7/10

8.7/15

12/20

18/30

21/35

26/35

Test VoltagekV

3.5

6.5

12.5

21

30.5

42

63

73.5

91

min

Test Time

5

5

5

5

5

5

5

5

5


 Structure of power cable

MV Power Cable


8.7/10(12)kV8.7/15(17.5)kV 1-core XLPE insulation PVC sheath power cable

Nominal Area

mm2

Non armored

Tape-armored

Wire-armored

Reference diameter

mm

Approximate weight

kg/km

Reference diameter

mm

Approximate weight

kg/km

Reference diameter

mm

Approximate weight

kg/km

YJV

YJLV

YJV62

YJLV62

YJV72

YJLV72

1*25

23.1

775

620

25.0

1063

884

28.7

1662

1483

1*35

24.1

900

683

26.0

1204

960

29.8

1828

1584

1*50

25.4

1080

770

27.3

1406

1064

31.2

2063

1721

1*70

27.0

1314

880

29.0

1672

1200

33.0

2371

1900

1*95

28.7

1601

1012

31.4

1980

1348

35.5

2971

2338

1*120

30.2

1881

1137

32.8

2278

1486

37.0

3315

2523

1*150

31.9

2213

1283

34.4

2631

1647

38.7

3721

2737

1*185

33.6

2590

1444

36.0

3026

1820

40.4

4168

2962

1*240

36.0

3173

1686

38.3

3647

2092

42.8

4864

3309

1*300

38.3

3801

1942

40.6

4312

2378

45.3

5605

3671

1*400

41.8

4831

2353

44.9

5400

2835

49.9

7250

4685

1*500

45.2

5889

2790

48.2

6518

3298

53.4

8510

5290



  8.7/10(12)kV8.7/15(17.5)kV 3-core XLPE insulation PVC sheath power cable

Nominal Area

mm2

Non armored

Tape-armored

Wire-armored

Reference   diameter

mm

Approximate weight

kg/km

Reference   diameter

mm

Approximate weight

kg/km

Reference diameter

mm

Approximate weight

kg/km

YJV

YJLV

YJV22

YJLV22

YJV32

YJLV32

3*25

47.7

2460

1988

52.5

3593

3121

55.7

5194

4722

3*35

49.9

2843

2192

54.9

4052

3401

58.1

5731

5080

3*50

52.9

3429

2499

58.1

4735

3805

61.3

6516

5586

3*70

56.7

4206

2905

61.9

5604

4303

65.2

7508

6207

3*95

60.4

5110

3343

66.0

6656

4889

69.1

8661

6894

3*120

63.6

5992

3761

69.4

7650

5419

72.6

9766

7535

3*150

67.3

7041

4252

73.1

8790

6001

76.2

11023

8234

3*185

70.9

8230

4790

76.9

10107

6667

81.5

13432

9992

3*240

76.1

10078

5616

82.3

12124

7662

86.8

15670

11208

3*300

81.2

12101

6524

88.8

15183

9606

92.1

18080

12503

3*400

87.9

15292

7856

95.7

18662

11226

99.0

21809

14373
